CLPs, IHMs e módulos OmronGuia de referências
CLPs, IHMs e módulos Omron. Consulte a lista de referências, documentação e orientações para cotação.
Disponibilidade e prazo são confirmados na cotação.
CLPs, IHMs e módulos OmronFotografia específica não disponível
Códigos e documentação
CLPs, IHMs e módulos Omron. Este é o ponto de navegação para controladores, interfaces de operação, módulos remotos e acessórios Omron. As famílias especializadas estão nos links abaixo; as tabelas desta página mantêm referências complementares. Identifique primeiro a função do componente e depois confirme o código completo no projeto e na etiqueta.
As tabelas abaixo contêm 110 referências com link direto por código. Use a busca para localizar o part number, inclusive sem espaços ou hífens; confirme sempre os sufixos antes de cotar.
Encontre a família antes do módulo
Use NX/NJ para navegar pelos controladores e módulos dessas plataformas, CJ/CS para as respectivas unidades modulares, CP1/CPM/ZEN para controladores compactos e NA/NB/NS para IHMs. Para expansão ou manutenção, informe a CPU instalada, a posição do módulo, a versão do projeto e a ligação existente. As tabelas complementares não substituem o catálogo específico de cada família.
Destaques da linha
| Imagem | Part number | Descricao | Familia | Datasheet |
|---|---|---|---|---|
| NX-OC4633 NXOC4633 | PLC Expansion Module, Relay Output Unit 8 NO, 250 VAC, 2A, NX Series | Sysmac NX e NJ | Datasheet | |
| NX-DA3203 NXDA3203 | PLC Expansion Module, 4 Analog Current Out, Free Run Refresh, NX Series | Sysmac NX e NJ | Datasheet | |
| NX-SL3300 VER1.1 NXSL3300VER11 | PLC Expansion Module, Safety CPU, 32 I/O, NX Series | Sysmac NX e NJ | Datasheet | |
| CJ1W-OC211 CJ1WOC211 | PLC Expansion Module, 16 Relay Outputs, 250VAC/24VDC, 2A, CJ1W Series | Sysmac CJ1 e CJ2 | Datasheet | |
| CJ1W-ID211 CJ1WID211 | Controllers, Programmable, Connect:Terminal Block, 16 Inputs, 7mA, 24VDC | Sysmac CJ1 e CJ2 | Datasheet | |
| CJ1W-ID231 CJ1WID231 | I/O module 32point | Sysmac CJ1 e CJ2 | Datasheet | |
| CS1W-CIF31 CS1WCIF31 | ACCESSORY, USB PROGRAMMING CABLE, CS1W Series | Sysmac CS1 | Datasheet | |
| CS1W-CLK23 CS1WCLK23 | PLC Expansion Module Controller Link Unit 5 V | Sysmac CS1 | Datasheet | |
| CS1W-AD081-V1 CS1WAD081V1 | PLC Expansion Module Input 8 Input, 5 V dc, 26 V dc 130 x 35 x 126 mm | Sysmac CS1 | Datasheet | |
| CP1L-EL20DR-D CP1LEL20DRD | Controller, Programmable, 20 I/O Points, 12 Inputs, 8 Outputs, DC | CLPs compactos CP1 e CPM | Datasheet | |
| CP1E-N30DT-D CP1EN30DTD | PLC, CPU unit, 18 In, 12 out(sinking), 24VDC, RS-232C, USB, RS-485, 8k words | CLPs compactos CP1 e CPM | Datasheet | |
| CP1L-L20DR-A CP1LL20DRA | PLC, CPU unit, 100-240 VAC, Relay, 12-In/8-Out, USB, CP1 Series | CLPs compactos CP1 e CPM | Datasheet | |
| ZEN-10C1DR-D-V2 ZEN10C1DRDV2 | Controller, CPU, 6 Inputs and 4 Outputs, DC Input, Relay Output, DC Power Supply | Micro-rele programavel ZEN | Datasheet | |
| ZEN-CIF01 ZENCIF01 | Cable, Programming, P.C. to ZEN Relay, RS-232 Serial to Zen, 2m | Micro-rele programavel ZEN | Datasheet | |
| ZEN-10C2DT-D-V2 ZEN10C2DTDV2 | CONTROL LOGIC 6 IN 4 OUT 24V | Micro-rele programavel ZEN | Datasheet | |
| CRT1-OD16 CRT1OD16 | Slave Unit Output Module 2-Tier Screw Terminal Block, 16 NPN Out, CRT1 Series | Modulos remotos GRT1, DRT2 e CRT1 | Datasheet | |
| DRT2-OD16-1 DRT2OD161 | PLC Expansion Module, 16 Output 24 Vdc, DRT Series | Modulos remotos GRT1, DRT2 e CRT1 | Datasheet | |
| DRT1-COM DRT1COM | PLC Expansion Module, Communication Unit, 1024 I/O, DeviceNet, DRT1 Series | Modulos remotos GRT1, DRT2 e CRT1 | Datasheet | |
| NA5-7W001B-V1 NA57W001BV1 | Programmable HMI, 7 in TFT LCD Touch, 6 Port, 24 VDC, IP65, Sysmac NA Series | IHMs NA, NB e NS | Datasheet | |
| NS8-TV00B-V2 NS8TV00BV2 | HMI Display NS8 8.4 in LCD Touch-ScreenColor 640x480 Pixels 315x241x48.5 mm | IHMs NA, NB e NS | Datasheet |
Modulos remotos GRT1, DRT2 e CRT1
| Imagem | Part number | Descricao tecnica | Datasheet |
|---|---|---|---|
| # CRT1-OD16 CRT1OD16 | Slave Unit Output Module 2-Tier Screw Terminal Block, 16 NPN Out, CRT1 Series | Datasheet | |
| # DRT2-OD16-1 DRT2OD161 | PLC Expansion Module, 16 Output 24 Vdc, DRT Series | Datasheet | |
| # DRT1-COM DRT1COM | PLC Expansion Module, Communication Unit, 1024 I/O, DeviceNet, DRT1 Series | Datasheet | |
| # GX-ILM08C GXILM08C | GX-series IO-LinkMaster Unit | Datasheet | |
| # DRT2-ID16 DRT2ID16 | PLC Expansion Module Input Terminal 16 Input, 24 VDC 115x53.1x49.7mm, DRT Series | ||
| # CRT1-ID16 CRT1ID16 | Slave Unit Input Module 2-Tier Screw Terminal Block, 16 NPN In, CRT1 Series | Datasheet | |
| # CRT1-TS04T CRT1TS04T | CompoNet 4 Pt Thermocouple | Datasheet | |
| -- | # CRT1-ID08 CRT1ID08 | CompoNet 8 NPN Inputs | |
| # CRT1-ID16-1 CRT1ID161 | 16 PNP DC Inputs | Datasheet | |
| # DRT2-TS04P DRT2TS04P | Temperature Resistance Thermometer 4 Input Terminal, 11-25 VDC, DRT Series | Datasheet | |
| # DRT2-OD16 DRT2OD16 | PLC Expansion Module, 16 NPN Output, DRT2 Series | Datasheet | |
| # GRT1-ID4-1 GRT1ID41 | PLC Expansion Module, 4 Digital DC Sourcing PNP Inputs, GRT1 Series | Datasheet | |
| # DRT2-AD04 DRT2AD04 | PLC Expansion Module Input Terminal 4 Input, 11 to 25 V dc 115 x 53.1 x 49.7 mm | Datasheet | |
| # DRT2-DA02 DRT2DA02 | PLC Expansion Module Output Terminal 2 Output 11 to 25 V dc 115 x 53.1 x 49.7 mm | Datasheet | |
| # DRT2-MD16TA-1 DRT2MD16TA1 | PLC Expansion Module, 8 NPN I/O, DR2T Series | Datasheet | |
| # GRT1-OD8G-1 GRT1OD8G1 | I/O Module, Smartslice 8pt Output Unit PNP | Datasheet | |
| # GRT1-OD8-1 GRT1OD81 | Module, Smartslice, 8 point output, PNP | Datasheet | |
| # GRT1-PRT(NL) GRT1PRTNL | Smartslice PROFIBUS-DP interface unit | Datasheet | |
| # GRT1-ID8-1 GRT1ID81 | I/O Module, Smartslice 8pt Input Unit, PNP | Datasheet | |
| -- | # CRT1-VOD32ML CRT1VOD32ML | 32 Out NPN MIL | Datasheet |
| # GRT1-OD4-1 GRT1OD41 | Smartslice 4-point PNP output unit | Datasheet | |
| # GRT1-CT1-1 GRT1CT11 | 1 ch. high speed counter unit 60kHz, PNP | Datasheet | |
| # CRT1-AD04 CRT1AD04 | 4 Analog Inputs | Datasheet | |
| # GRT1-ROS2 GRT1ROS2 | Smartslice 2-point Relay output unit | Datasheet | |
| # GRT1-ID4 GRT1ID4 | Smartslice 4-point NPN input unit | Datasheet | |
| # GRT1-END GRT1END | Smartslice End plate, 1 per interface | Datasheet | |
| # GRT1-DA2V GRT1DA2V | Smartslice 2-Channel voltage output unit | Datasheet | |
| # GRT1-PD2 GRT1PD2 | I/OpowerFeddMod,24VDCinput | Datasheet | |
| # GRT1-DRT GRT1DRT | PLC Expansion Module, 64 IO Port DeviceNet Communication, GRT1 Series | Datasheet | |
| # GRT1-DA2C GRT1DA2C | Smartslice 2-Channel current output unit | Datasheet | |
| # DRT2-ID16S-1 DRT2ID16S1 | DeviceNet Smart Slave Input 16Pt DRT2 | Datasheet | |
| # CRT1-DA02 CRT1DA02 | 2 Analog Outputs | Datasheet | |
| # DRT2-ID16-1 DRT2ID161 | PLC Expansion Module Input Terminal 16 Input, 24 V dc 115 x 53.1 x 49.7 mm | Datasheet |
Cabos, terminais e acessorios
| Imagem | Part number | Descricao tecnica | Datasheet |
|---|---|---|---|
| # XW2Z-200S-CV XW2Z200SCV | RS232 cable PLC range cable,2m | Datasheet | |
| # CXONE-AL01D-V4-UP CXONEAL01DV4UP | PLC Programming Software, CX-One Automation, Single License, Upgrade Only | Datasheet | |
| # XW2D-40G6 XW2D40G6 | Terminal Block For Use With CJ1M Series | Datasheet | |
| # CXONE-AL01D-V4 CXONEAL01DV4 | PLC Programming Software,V4,For Various Operating Systems | Datasheet | |
| # C200H-CN229-EU C200HCN229EU | Accessory | Datasheet | |
| # XW2Z-100K XW2Z100K | Cable,1m,for use with RS510-1524 | Datasheet | |
| -- | # XW2Z-200S | 2M CABLE, PLC TO XW2B | |
| -- | # C200H-OD217 C200HOD217 | 12PT-TRAN: 0.3A, 5-24VDC | |
| -- | # XW2Z-200T-3 XW2Z200T3 | ACCESSORY | Datasheet |
| # CXONE-AL00D-V4 CXONEAL00DV4 | CXONE DVD Only - No Lic | Datasheet | |
| # C200HW-PD024 C200HWPD024 | Power Supply, 24? V DC Input, 5? V DC/4.6?A Output, 30?W, Backplane Mount | Datasheet | |
| # CQM1-CIF02 CQM1CIF02 | Cable,Program Download Cable to 9 Pin Computer Serial Port,10.8 Feet cable lengt | Datasheet | |
| -- | # XW2Z-200EE XW2Z200EE | FH ParI/O Cbl to tem Block 2M | Datasheet |
| # XW2Z-500T | 5m CABLE, PLC TO XW2B | Datasheet | |
| # C200HS-CN220-EU C200HSCN220EU | PLC Connecting Cable, D-Dub 9-Pin, 2m, C Series | Datasheet | |
| # XW2D-50G6 XW2D50G6 | Slim Connector Terminal Block | Datasheet | |
| # XW2Z-100B | 1M CABLE FOR SCREW TERMINAL | Datasheet | |
| -- | # C200H-CN222 C200HCN222 | PRO27 CABLE, 2M (6.5 FT) | |
| -- | # C200H-MAD01 C200HMAD01 | ANALOG 2 INPUTS / 2 OUTPUTS | |
| -- | # XW2Z-200T-4 | Cbl for PLC-NV,2m,5VDC Only | Datasheet |
| # XW2Z-150B XW2Z150B | Cable Devicenet 32point 1.5M | Datasheet | |
| -- | # C200H-CN221 C200HCN221 | C200H I/O CABLE, 2M | |
| -- | # C200H-PRO27-E C200HPRO27E | PROGRAM UNIT | |
| # XW2Z-200S-V XW2Z200SV | 2M CABLE FOR SCREW TERMINAL | Datasheet | |
| # C200H-SP001 C200HSP001 | Space Unit For Use With C200HW Series, CS1W Series | Datasheet |
Outros itens da selecao
| Imagem | Part number | Descricao tecnica | Datasheet |
|---|---|---|---|
| # CP2E-S60DT-D | CP2E CPU,RS-232, RS-485 ,36 TTL Inputs 24, Outputs TTL sinking, 3 expansion, DC | Datasheet | |
| # SYSMAC-SE201L SYSMACSE201L | Sysmac Studio Automation Software for NJ/NX/NY Controllers, 1 User | Datasheet | |
| # SYSMAC-LE201L SYSMACLE201L | Sysmac Studio Lite, 1 User, For NJ1 and NX1 Controllers, NXJQ1 | Datasheet | |
| # F3SP-B1P | F3SP-B1P | Datasheet | |
| # DRS2-1 DRS21 | PLC Accessories, Terminating Resistor M12 Female Plug Model, E5EK-DRT Series | Datasheet | |
| # EST2-2C-MV4 EST22CMV4 | CX-Thermo Support Programming Software, E5C Temperature Controller, EST2 Series | Datasheet | |
| # CP2E-S40DT-D | Micro PLC, 24 TTL In, 16 TTL Out Sink, 3 Expansion, CP2E Series | Datasheet | |
| -- | # R88A-CNU01C R88ACNU01C | CN1 I/O Connector GN | |
| # E53-R E53R | Module, 4, 250 VAC, 5 A, 190 ms, UL Listed, CSA Certified, CE Marked, ES3 Series | Datasheet | |
| # DST1-MRD08SL-1 DST1MRD08SL1 | I/O MODULE 4 DIGITAL 8 RELAY SS | Datasheet | |
| -- | # SRT2-ID08 | 8PT.INPUT,NPN, SRT27002C | |
| # CP2E-E30DR-A | Micro PLC, 18 TTL In, 12 Relay Out, 24 VDC, 0.5A, CP2E Series | Datasheet | |
| # R88A-CNW01C | Connector for CN1, R8AW6045E | Datasheet | |
| # XW4B-05C4-TF-D XW4B05C4TFD | Connector, Multi-Branching, Screw Type, Same-Direction Insertion and Wiring | Datasheet | |
| # K34-C1 K34C1 | Option card K34-C1 For Use With K3HB Digital Indicator | Datasheet | |
| # B7A-T6C1 B7AT6C1 | Link Input Module, 16 Points, 16 PT PNP IN +/-COM 19.2MS, B7A Series | Datasheet | |
| # DST1-MD16SL-1 DST1MD16SL1 | Safety I/O Terminal, 8 Inputs, 8 Outputs, 4 Test Outputs, DST1 Series | Datasheet | |
| # G70A-ZOC16-3 DC24 G70AZOC163DC24 | PLC Expansion Module Terminal Base 24 V dc | Datasheet | |
| # E53-COV17 E53COV17 | Accessory, for E5CN Temp Controller, Terminal Block Cover | Datasheet | |
| # GT1-AD04 GT1AD04 | MULTIPLE I/O, ANALOG INPUT | Datasheet | |
| # E53-CNHBN2 E53CNHBN2 | Accessory, for E5CN Temp Controller, Event Inputs, Htr BrnOut/SSR Fail/OverCurr | Datasheet | |
| # XWT-ID16 XWTID16 | Smart Slave Expansion Module, 16 NPN Input, XWT Series | Datasheet | |
| # SYSMAC-NE001L SYSMACNE001L | Sysmac Studio NX StandAlone License | Datasheet | |
| # DCN4-TB4 DCN4TB4 | Adapter For Use With CRT1 Series | Datasheet | |
| # 3G3AX-MX2-EIP-A 3G3AXMX2EIPA | MX2 EtherNet/IP Comm Card | Datasheet | |
| # HMC-EF183 HMCEF183 | Memory Module For Use With CJ Series, CS Series, NSJ Controller | Datasheet | |
| # XWT-ID16-1 XWTID161 | SMART SLAVE EXP,16 PNP IN | Datasheet | |
| # SRT2-ROC16 SRT2ROC16 | PLC Expansion Module, Remote IO Terminal, 16 Port, Relay Output Mnt, SRT2 Series | Datasheet | |
| # C500-CE404 C500CE404 | Connector MODULE 32 POS FOR CQ1M | Datasheet | |
| # SYSMAC-SE200D | Sysmac Studio DVD ONLY, NXSS0001R | Datasheet | |
| # XWT-OD08-1 | SMART SLAVE EXP,8 PNP OUT | ||
| -- | # FH-VPX-FZ FHVPXFZ | FH-L/FZ IO Conv Cable 0.5M | |
| # FH-L550 FHL550 | FH-Lite controller (2ch) | Datasheet | |
| -- | # SRT2-DA02 | PLC Expansion Module, 16 Analog Output, CompoBus/S Slave, Srt20010F, SRT2 Series | |
| # V600-D23P66N V600D23P66N | 256 B RFID Transceiver, 34 x 34 x 3.5 mm | Datasheet | |
| # SRT2-ROC08 SRT2ROC08 | PLC Expansion Module, 8 Relay Outputs, 50x100x50mm, 3A, SRT2 Series | Datasheet | |
| # SRT2-ID16-1 SRT2ID161 | PLC Expansion Module, 16 Input PNP, 24VDC, 105x48x50mm, SRT2 Series | Datasheet | |
| -- | # SRT2-OD16-1 SRT2OD161 | OUTPUT MODULE 16 SOLID ST 24VDC | Datasheet |
| -- | # S82S-7312 | 12V,0.25A OUTPUT,DC12-24 INPUT, H | |
| -- | # SRT2-ID16 | 16PT.INPUT,NPN, SRT27004M | |
| # NV3Q-MR21 NV3QMR21 | HMI 3.6" Touchscreen Monochrome 320x240 Pixels 24VDC CP1 Series | Datasheet | |
| # SYSMAC-SE203L SYSMACSE203L | Sysmac Studio Automation Software for NJ/NX/NY Controllers, 3 users | Datasheet | |
| -- | # PPC-3100S-OMR | FHV7 Touch Panel Monitor 10.4", AD101790M | Datasheet |
| # NV-TOL-3M NVTOL3M | PLC connection cable For Use With HMI NV3W | Datasheet | |
| -- | # R88A-CNU11C R88ACNU11C | CN1 I/O Connector GT | Datasheet |
| # CRS1-RPT01 CRS1RPT01 | Repeater Unit | Datasheet | |
| # XW4G-05C4-TF-D XW4G05C4TFD | Connector For Use With DeviceNet Communication | Datasheet | |
| -- | # SRT2-ID08-1 | 8PT.INPUT,PNP, SRT27003A | |
| # CP2E-N20DR-A | CP2E CPU, 1 Ethernet port, 12 TTL Inputs 8 Relay Outputs ,1 Option port, AC | Datasheet | |
| # NV3Q-SW21 NV3QSW21 | HMI 3.6" Touchscreen Color 320x240 Pixels 24VDC CP1 Series | Datasheet | |
| -- | # NV3W-MR20-V1 NV3WMR20V1 | HMI NV 3.1 | |
| -- | # TJ1-FL02 TJ1FL02 | Flexible Axis Unit(for 2 axis) |
Como solicitar cotação
Informe part number completo, quantidade, aplicação e dados do equipamento instalado. Envie fotos quando houver dúvida de identificação. Preço, disponibilidade e prazo são confirmados na proposta; a lista de códigos não indica estoque imediato.
Identificação da referência
Dados do CLPs, IHMs e módulos Omron
| Código de referência | CLPs, IHMs e módulos Omron |
|---|
Referência preservada do cadastro Mokka. Os parâmetros da configuração devem ser conferidos no documento do fabricante antes de selecionar ou substituir o item.
Seleção e reposição do CLPs, IHMs e módulos Omron
Antes de solicitar CLPs, IHMs e módulos Omron, confira os pontos abaixo:
- Confira alimentação, entradas e saídas, terminais, montagem e os sufixos do código completo.
- Informe todos os sufixos e a revisão. Códigos parecidos não garantem equivalência.
- Para reposição, envie foto legível da etiqueta e confirme a aplicação com a equipe.
Informe o código completo CLPs, IHMs e módulos Omron e a quantidade. Para reposição, envie também uma foto legível da etiqueta, e do equipamento no qual será utilizado.
Documentação do CLPs, IHMs e módulos Omron
Omron — catálogo do fabricantePortal para consulta. Este link não comprova os parâmetros desta referência.Ficha organizada em 28 de outubro de 2026. A origem dos dados e os limites da conferência estão indicados nesta página. Confirme a revisão, a compatibilidade com a aplicação e as condições de fornecimento.
Outros códigos desta família
As referências abaixo possuem configurações próprias. A proximidade do código não confirma equivalência.
