Observação: O status do produto do fabricante é Descontinuado. Compatibilidade técnica com as séries HC-SFS e HC-LFS.
Para mais informações sobre este produto ou para consultar outras soluções, entre em contato conosco.
Especificações
| Parâmetro | Valor |
|---|---|
| Primary brand | Mitsubishi Electric |
| Main function | AC servo drive |
| Product series / family name | MELSERVO J2S series |
| Sub-range name | MR-J2 series |
| Functions | AC motion servo drive / amplifier sine wave PWM control/current control method |
| Design | built-in dynamic brake forced ventilation cooling SSCNET III/H |
| Supply voltage (AC) | 380Vac-480Vac (400V class; 400Vac / 415Vac / 440Vac) |
| Type of network | 3-phase input (3P) |
| Rated active power (kW) | 2000W / 2kW |
| Protection functions | overcurrent shut-off regeneration overvoltage shut-off overload shut-off (electronic thermal) servo motor overheat protection encoder fault protection regeneration fault protection undervoltage/sudden power outage protection overspeed protection excessive error protection |
| Digital inputs | 1 x digital input (24Vdc; sink/source) (EM1) |
| Digital outputs | 1 x digital relay output (MBR) |
| Analog outputs | 1 x analog output (-10…+10Vdc) (MO1) 1 x analog output (-10…+10Vdc) (MO2) |
| Dimensions | H168mm x W90mm x D195mm |
| Net Height (mm) | 168 mm |
| Net Width (mm) | 90 mm |
| Net Depth (mm) | 195 mm |
| Ambient air temperature for operation | 0…+55 °C |
| Ambient air temperature for storage | -20°C…+65 °C |
| Power consumption | (drive auxiliary power consumption) 25 W |
| Technical compatibility with | HC-SFS series HC-LFS series |
| Order code / Manufacturer SKU | MR-J2S-200B4 |
| Manufacturer product status | Discontinued |
