Disjuntor Mitsubishi BHW-T 2P 6A Curva C 10kA Disjuntor Miniatura BHW-T10-1PN-6A-C da Mitsubishi Electric, 2 polos (1P+N), 6A, Curva C, 10kA. Proteção confiável para sua instalação.
Especificações
| Parâmetro | Valor |
|---|---|
| Primary brand | Mitsubishi |
| Main function | Miniature Circuit Breaker (MCB) |
| Product series / family name | BHW-T series |
| Functions | Miniature Circuit Breaker (MCB) |
| Poles | 2-poles (1P+N) |
| Rated current | 6A |
| Rated insulation voltage (Ui) | 660 V |
| Connection type | Cage-clamp |
| Tripping curve | C |
| Short circuit current breaking capacity (Icn) | 10 kA |
| Protection functions | Thermal protection (Overload) Magnetic protection (Short-circuit) |
| Mounting mode | Surface mounting (or DIN rail with optional adapter) |
| Dimensions | W36mm x H92.6mm x D73.5mm |
| Electrical durability (with load) | 4000 operations |
| Mechanical durability (at no load) | 4000 operations |
| Manufacturer product status | Commercialized |
| Equivalent to | BHWT101PN6AC |
| Compliant with standard(s) | IEC 60898-1 EN 60898-1 CE marking |
| Benefits | High-quality high-performance circuit breakers suitable for household electrical distribution panels All models fully comply with IEC regulations Compliance with IP2X protection rating (front surface) All models are compatible with reverse connection Rated currents up to 100A for MCBs Accessories suitable for field fitted for MCBs (80 to 100A) |
