Contator Reversor Mitsubishi Electric S-N180 AC400V. Com 180A, 3 polos, bobina 380-440Vac e 2NA+2NF contatos auxiliares. Ideal para aplicações industriais.
Especificações
| Parâmetro | Valor |
|---|---|
| Primary brand | Mitsubishi Electric |
| Main function | Contactor |
| Product series / family name | MS-N series |
| Functions | Magnetic contactors reverser assembly |
| Rated current | 180A (240Vac; AC-3) 180A (380Vac / 400Vac / 415Vac / 440Vac; AC-3) 220A (UL continuous current rating) 260A (AC-1) |
| Rated active power (kW) | 55kW (240Vac; AC-3; IEC) 90kW (440Vac; AC-3; IEC) |
| Rated power (HP) | 15HP (120Vac; Single-phase; UL) 30HP (240Vac; Single-phase; UL) 60HP (208Vac; 3-phase; UL) 60HP (240Vac; 3-phase; UL) 125HP (480Vac; 3-phase; UL) 125HP (600Vac; 3-phase; UL) |
| Rated operating voltage (Ue) | 690 V |
| Connection type | Mech. lugs connections |
| Poles | 3 Pole(s) |
| Control Voltage (AC) | 380Vac-440Vac (50Hz/60Hz) (400Vac / 415Vac) |
| Mounting mode | Surface |
| Normally Open (NO) auxliary contacts | 2 NO contacts |
| Normally Closed (NC) auxiliary contacts | 2 NC contacts |
| Number of Normally Open (NO) circuits | 3 NO Pole(s) |
| Degree of protection | IP00 |
| Electrical durability (with load) | 1 000 000 operations |
| Mechanical durability (at no load) | 5 000 000 operations |
| Application type | Direct On Line (DOL) FVNR (Full-Voltage Non-Rv.) |
| Manufacturer product status | Commercialized |
| Equivalent to | S-N180AC400V |
| Compliant with standard(s) | CE TUV Rheinland cULus UL Listed cUL CCC LR (Lloyd’s Register) BV (Bureau Veritas) KR (Korean Register of Shipping) NK (Nippon Kaiji Kyokai) |
