Bloco Contato Auxiliar ALAX-4SWL Mitsubishi Bloco de contato auxiliar e alarme ALAX-4SWL da Mitsubishi Electric para disjuntores WS-V 400-800A, tipo SPDT x2.
Especificações
| Parâmetro | Valor |
|---|---|
| Primary brand | Mitsubishi |
| Main function | Auxiliary contact |
| Functions | Auxiliary and alarm contact switch block |
| Design | standard type for left pole |
| Rated current | 3A (250Vac; AC-1) 4A (30Vdc; DC-1) |
| Contacts type | SPDT (Single Pole Double Throw) NO/NC (trip status) + SPDT (Single Pole Double Throw) NO/NC (ON/OFF position) |
| Technical compatibility with | WS-V series frame size 400A-800A |
| Manufacturer product status | Commercialized |
| Equivalent to | ALAX4SWL |
| Benefits | The internal accessories for major models having a frame size from 30A to 800A come in cassettes and they can be installed to and removed from circuit breakers by the user. Some cassette type accessories have lead wires drawn out; and others have vertical lead wire terminal blocks (SLT) |
